BR Mast Series

Diameter Of Base Section: 15.24cmin

No. of Sections: 6

Vertical Headload: 150kg

Weight: 49.9

BR30W

Diameter Of Top Section: 8.89cmin

Height Extended: 9.1m

Height Retracted: 2.1m

Max. Wind Speed Unguyed: 74.5kph

No. of Sections: 6

Vertical Headload: 150kg

Weight: 54.4

BR42W

Max. Wind Speed Unguyed: 62kph

Height Extended: 12.8m

Height Retracted: 2.3m

No. of Sections: 9

Weight: 108.9

BR48W

Max. Wind Speed Unguyed: 56kph

Height Extended: 14.6m

Height Retracted: 2.7m

No. of Sections: 8

Weight: 127

BR52W

Max. Wind Speed Unguyed: 45kph

Height Extended: 15.8m

Height Retracted: 2.7m

No. of Sections: 9

Weight: 136

BR56W

Max. Wind Speed Unguyed: 49kph

Height Extended: 17m

Height Retracted: 3m

No. of Sections: 8

Weight: 143

Personalised solutions

Whether you need a single antenna or a complete RF system, get the right products for your project. Request your quote now.

Choose a Product

BR25W

Height Extended (m): 7.6

Height Retracted (m): 1.8

Number of Sections: 6

Weight (kg): 49.9

Vertical Head Load (kg): 150

Diameter of Base Section (cm): 15.24cm

BR30W

Height Extended (m): 9.1

Height Retracted (m): 2.1

Number of Sections: 6

Weight (kg): 54.4

Vertical Head Load (kg): 150

Diameter of Base Section (cm): 15.24cm

BR42W

Height Extended (m): 12.8

Height Retracted (m): 2.3

Number of Sections: 9

Weight (kg): 108.9

Vertical Head Load (kg): 250

Diameter of Base Section (cm): 22.86cm

BR48W

Height Extended (m): 14.6

Height Retracted (m): 2.7

Number of Sections: 8

Weight (kg): 127

Vertical Head Load (kg): 250

Diameter of Base Section (cm): 22.86cm

BR52W

Height Extended (m): 15.8

Height Retracted (m): 2.7

Number of Sections: 9

Weight (kg): 136

Vertical Head Load (kg): 250

Diameter of Base Section (cm): 22.86cm

BR56W

Height Extended (m): 17

Height Retracted (m): 3

Number of Sections: 8

Weight (kg): 143

Vertical Head Load (kg): 250

Diameter of Base Section (cm): 22.86cm

Related PRoducts

Climbing Steps

Enhance your field applications with SMC’s Climbing Steps. Our Climbing Steps are invaluable accessories that offer easy access to locking collars and antennas during field operations. These mast climbing steps are designed to clamp onto any position of the mast’s lower section and can be conveniently folded upright for transit. They are designed to provide safe and secure access and are typically used by technicians or maintenance workers who need to ascend or descend masts for various purposes, such as inspection, maintenance, or installation of equipment. Safety precautions, including the use of appropriate personal protective equipment (PPE) such as harnesses and helmets, are crucial when working at heights. Always follow manufacturer guidelines and industry safety standards when using mast climbing steps or any other equipment for working at elevated heights. We offer single steps for climbing and double steps for resting, ensuring your safety and convenience during mast operations.

Nycoil

Nycoil, a specialized tubing, serves as a protective sheath, ensuring that wires and cables are neatly arranged and secured during mast operations.

To meet specific requirements associated with this accessory, we highly recommend reaching out to us before making your Nycoil selections. Our team will provide expert guidance to ensure the perfect fit for your needs.

For masts requiring electrical wiring to the masthead, SMC strongly recommends using Nycoil for optimal wire management. Nycoil is available in standard black or red and comes in the following sizes: 1 1/4″ 1″ 3/4″ At SMC, we offer quotes for Nycoil both with and without wire, tailored to your exact specifications. Our customer support team is ready to assist you with any inquiries and provide personalized quotes. Simply reach out to us using the contact form below for prompt assistance. Experience the efficiency and reliability of the SMC Nycoil Wire Management System – ensuring a seamless and secure setup for your mast wiring needs.

Plug-n-Go Compressor

Our Plug-n-Go Compressors are your ultimate choice for reliable, versatile, and easy-to-use air compressors, available in two power options: 12V DC or 115V AC. With a user-friendly design, these compressors feature a regulator, a pressure cut-off switch, an electronic dump valve, and a psi gauge, ensuring straightforward operation and precise control. Their compact size and portable nature make them perfect for on-the-road use, particularly in broadcast vehicles. Safety is paramount with the electronic quick dump safety exhaust, offering swift and secure mast retraction. Enclosed in a rugged and water-resistant case with a convenient handle, the SMC Plug-n-Go Compressor is built to withstand demanding conditions. Choose from optional colors, such as camouflage, black, or tan, based on availability, to match your preferences. Rest assured, all SMC Plug-n-Go Compressors are CE & UL rated, meeting high standards of safety and performance. Experience the convenience and reliability of the SMC Plug-n-Go Compressors – your go-to solution for a wide range of applications, both on and off the road.

Vehicle Roof Bearings

SMC’s Vehicle Roof Bearings are essential accessories for securely mounting masts through the roof of your vehicle. The assembly consists of an upper and lower aluminium bearing, designed to ensure stability and ease of use. The upper bearing comprises three separate components: a flange with a Teflon ring, securely bolted to the vehicle’s outer skin, a tapping plate, and a weatherproof shield that clamps firmly onto the mast. This design guarantees a reliable and weather-resistant setup. The lower bearing base plate features a Teflon disc, allowing effortless rotation of your mast, and a thumb screw for locking it into position. For our NX Series masts, an optional locking collar is available. The base plate is securely bolted to the vehicle floor using four M12 bolts spaced on a 5.5″ P.C.Dia.
