HFH2-1 – 2 x 1kW HF Broad Band Hybrid Combiner

Quick Information

RF Communications

Connectors

Construction

Environment

Frequency

Impedance

Input Power

Insertion Loss

Isolation

Load Ports

Load VSWR

Output Power

Temperature

VSWR

Weight (kg)

HFH2-1 - 2 x 1kW HF Broad Band Hybrid Combiner

Connectors: 'N'

Construction: Cast aluminium case, solid encapsulation, epoxy paint finish

Environment: Outdoor unprotected

Frequency: 1.5 - 32MHz

Impedance: 50 ohm

Input Power: 2 x 1kW average (2kW peak)

Insertion Loss: <0.25 dB (matched loads)

Isolation: >30 dB (matched loads)

Load Ports: 2 x 50 ohm 'N' Connectors

Load VSWR: 2.5 : 1 max

Output Power: 2kW average (4kW peak)

Temperature: -40°C to +70°C

VSWR: <1.2 : 1 max
